Heavy-Duty DSP Processing and Upsampling with Roon

• Solid and silent aluminum enclosure without any moving parts
• Passive cooling enables plenty of CPU processing power for Roon
• Audio-optimized, low-latency, high-efficiency, light-weight reliable and unbreakable operating system - exaOS
• 6-core Intel i5 processor
• Memory size 32GB, upgradable to 64GB
• Fast 2TB system/data SSD drive
• Up to two additional 4TB SSD drives for data storage
• Support for Wi-Fi network connections
• Completely redesigned user interface with dark and light themes

Roon Server

• Streams music to any device compatible with Roon Server: USB DACs, Roon Ready, Roon Tested, AirPlay, Chromecast, Sonos, HDMI, Devialet, KEF, Meridian, Squeezebox and other
• Integrates Qobuz, Tidal, Internet Radio
• Stereo and multichannel upsampling to DSD512, support for multiple DSD plug-ins
• Manages your music collection and stores the Roon database on the built-in SSD system drive
• Plays your music files stored on internal SSD storage, USB drives and NAS
• Industry best ergonomics - playback is controlled by the Roon Remote app available on iPad, iPhone, macOS, Android, and Windows
• Requires Roon subscription

Roon is a subscription-based, multi-room, multi-user networked audio platform built to the demanding standards of audiophiles. It offers bit-perfect playback, DSD and PCM upsampling, Stereo and multichannel playback, and signal path display.

High-end Sonic fidelity

All exaSound Delta Server models offer a choice of the best audio streaming and processing technologies that deliver consistent high-end sonic fidelity

• UPnP Server, UPnP/OpenHome Player
• Roon Server and Roon Player
• Signalyst NAA Player

Special integration with exaSound DACs offers enhanced user experience and exceptional fidelity.

exaDirect™ Bitperfect, minimum processing signal path

ZeroJitter™ Asynchronous Bitperfect Packet Streaming over USB

ZeroResolutionLoss™ Volume Control

• All-time 0dB full-scale streaming
• 4-way volume synchronization
• Volume trimming for individual channels
• Volume bypass

ENclusiv™ Comprehensive Sampling Rate Support in Stereo and Multi-channel

• Native DSD64, DSD128, DSD256, DSD512
• DXD 352.8kHz /32bit
• PCM 44.1 to 384kHz/32bit

exaSound DACs connected via USB to the Delta Server operate as Roon Ready devices. Unique asynchronous packet streaming over USB developed by exaSound guarantees that CPU load cased by multiple server tasks does not affect the timing accuracy and precision of local USB playback. With one device audiophiles can have it all - reverence-quality music server and top-performance renderer.



Roon Ready is the highest level of Roon integration. Roon technology is customized and embedded both in the player and the DAC for achieving best user experience. Together, Roon and exaSound deliver the power, flexibility, and performance benefits of networked audio, with the easiest setup and highest reliability available.




Web Streaming - Experimental

• YouTube and YouTube Music with video support
• Qobuz with high-resolution audio support
• TuneIn Radio
• MQA Full Unfold with Supported DACs

Bluetooth Streaming

• Streaming via Bluetooth from phones and tablets

Streaming

• Tidal, Qobuz and internet Radio are available via Roon, AirPlay and third-party apps including Bubble UPnP and MconnectHD
• Spotify is available via AirPlay
• Audio streaming protocols: Roon RAAT, Signalyst NAA, UPnP, Open Home, AirPlay



Technologies

• Networking: Gigabit Ethernet
• Ready for use for most applications right out of the box with zero-configuration
• Advanced configurations are available via Web-browser user interface
• Remote Support, Remote Diagnostics, Remote Upgrades

Custom-Order Upgrade Options

• RAM upgrades up to 64GB
• Up to two additional 4TB solid state drives
• CPU upgrade to 12-core i7 processor

Contact us for a free consultation and to order a custom configuration Delta Music Server.

	Delta Server M200	Delta Server M150
CPU	Intel 12-core i7	Intel 6-core i5 Custom upgrade option to Intel 12-core i7
RAM	New: 64GB	32GB Custom upgrade option to 64GB
System/Data SSD Drive	2TB	1TB Custom upgrade option to 2TB
Optional Additional Internal SSD Drives	Custom upgrade options - up to two 4TB SSD Drives
Music Library	Over 200,000 Tracks
Roon Core Multi-room Capacity	Over Five Zones, Typical	Yes
Network Connection	Gigabit Ethernet, Wi-Fi 80211ac
USB Ports	4x USB 3, 2xUSB 2
HDMI	User interface for configuration settings Roon multichannel and Stereo audio output
Display Port	Roon multichannel and Stereo audio output
Power Supply	Input: 100-240V~, 3A, 50-60Hz	Input: 100-240V~, 3A, 50-60Hz
Power Consumption	30-300W	30-240W
Chassis	Premium Grade Extruded Aluminum, Black	Premium Grade Extruded Aluminum, Black or Silver Finish
Dimensions	10.3 x 10.3 x 10.8 in 260 x 260 x 275 mm (W x D x H)	17.2 x 12.8 x 2.4 in 435 x 325 x 60mm (W x D x H)
Weight	9.5 Kg / 21 lbs	4.2 Kg / 9.3 lbs
Package Dimensions	356 x 356 x 405 mm 14 x 14 x 16 in (W x D x H)	565 x 315 x 165 mm 22 x 12 x 6 in (W x D x H)
Package Weight	11.5 Kg / 25.4 lbs	5.7 Kg / 12.6 lbs

exaSound Delta Music Server Mark II Owner’s Manual.pdf
